Mini-VNA Tiny  - Antenna Analyzer up to 3 GHz

MINI VNA PRO BT

3295,00 KR

Frequency range 0.1-200 MHz
- Calibration using open-short-load for accurate results
- Range of Z from 1 to 1000 ohm
- Two ports VNA with S11 and S21; displayed and save results
- I/Q DDS Generator with output power of 0 dBm
- Two separate RF output I/Q for SDR experiment and IMD test with independent 0-55 dB attenuator; Phase adjustment resolution of 1 degree
- Built in Bluetooth Class 1 for remote measurements
- Internal Battery Li-ion with 1000 mA/h (4 hours full- scan operation)
- Built-in battery charger (up to 400 mA)
- Accessory port for future optional interfaces and frequency extenders
- Low power
consumption, 220 mA @ 3.6 V (analyzer mode using USB port)
- Power save mode
- SMA connectors for better isolation
- Extended dynamic range up to 90 dB in Transmission & 50 dB in Reflection
- Boot loader for future firmware upgrades
- User friendly interface for PC Windows / Linux and Mac
- Integrated Smith chart in software
- Optional extender for UHF and SHF band (under development)
- Mobile Phone software (under development)

Measurements of motional crystal parameters, cable length, & more
- Export data in several formats JPEG, EXCEL, ZPLOT, S2P, PDF

mRS miniVNA-EXT

MINI VNA EXTENDER

200 MHZ—1500 MHZ

2795,00 KR

Tekstboks:                  MINI –VNA  NETWORK ANALYZER

                       MINI VNA HOMEPAGE

Specifications:

• Frequency range 1MHz – 3GHz
• Calibration using open-short-load for accurate results
• Range of Z from 1 to 1000 ohm
• Two ports VNA with S11 and S21; displayed and save results
• RF Generator with output power of -6dBm @ 500 MHz
• Powered from USB
• SMA connectors for better isolation
• Dynamic range – up to 70 dB @ 500 MHz
• Boot loader for future firmware upgrades
• User friendly interface for PC Windows Linux and Mac
• Integrated Smith chart in software
• Android Mobile Phone software
• Export data in several formats JPEG, EXCEL, ZPLOT, S2P, PDF



MINI VNA TINY

3695,00 KR

KALIBRERINGS KIT 295,00 KR
