Linear Amp Gemini 4 - 70MHz 300W Solid State Linear Amplifier

GEMINI POWER AMPS

VERSIONER FOR 144  SAMT  50/70  MHZ  220 VOLT  OUTPUT 300 WATT INPUT 3--25 WATT

Designed, manufactured and assembled entirely the UK, the all new GEMINI linear amplifier is a solid state linear amplifier with 300W output available in 6, 4 and 2m versions.
Designed to fill a market gap between the low power outputs of transverters and smaller rigs and the 1kW plus amplifiers that not all users want or can afford the Gemini range combines low drive requirements with instant on solid state performance in a compact stylish package.

With an RF section designed exclusively for us by Chris Bartram GW4DGU (of Mutek fame), Gemini uses the latest Freescale MRFE6VP6300HR3 LDMOS device for high performance and maximum ruggedness. This, combined with built in protection for overdrive, High SWR and over temperature ensures solid reliable performance at high outputs for long periods.

Furthermore GEMINI is a complete turnkey solution incorporating a complete 50V linear power supply so no external PSU is required.

Orders now being taken for delivery December/January.

PRIS :

50 /70MHZ  DUAL  8900,00 KR

144 MHZ                   9900,00 KR

432 MHZ                 12900,00 KR





                 50/70/144 MHZ  LINEAR AMP



Frequency coverage

50-54 MHz/ 70-72 Mhz

Power output @ 1dB compression

300W

Power output @ -30dB IMD3

>250W

Input power



3-25W (specified when ordered)

Spurious outputs

<-70dB wrt 300W

Input return loss

>13dB

Efficiency (RF)

>65%

RF Device

1 x Freescale MRFE6VP6300H

Protection

Overdrive, SWR, Over Temperature

Relays

Coaxial Output and Input

Metering

RF output

Power requirements

230V AC  50/60Hz

Dimensions mm

270w x 300d x 120h

Weight

10Kg

 DATA FOR 4 METER UDGAVE
